RF4463PRO wireless module: A world-leading high-performance wireless communication solution

RF4463PRO wireless module is a high-performance wireless communication module meticulously designed and developed by the NiceRF team. It utilizes the Silicon Lab si4463 C version device and has passed multiple international certifications, including FCC ID, CE-RED, and IC ID, ensuring compliance with wireless communication standards in various regions around the world. Whether in terms of technical performance or certification compliance, the RF4463PRO provides excellent support and assurance for customers.

Performance Features Overview: Cutting-Edge Technology and Efficient Transmission

RF4463PRO module utilizes (G)FSK narrowband transmission technology combined with imported original chips, ensuring high signal integrity and efficiency. Its receiving sensitivity reaches -126 dBm, paired with an output power of +20 dBm, allowing it to perform excellently in long-distance transmission and complex environments, ensuring signal reliability and stability. The module supports a wireless wake-up feature, requiring only 10 mA of receiving current to achieve quick wake-up from sleep mode, providing users with a more flexible experience.

Additionally, the RF4463PRO module offers a wide voltage supply range of 1.8-3.6V and supports multiple modulation modes, including (G)FSK, (G)MSK, and ASK, with data transmission rates ranging from 0.1 to 1000 Kbps, making it suitable for various high-speed or low-speed wireless communication scenarios.

RF4463PRO wireless modulehas obtained multiple international certifications, including FCC, CE, and IC, providing convenience for customers during product compliance certification. This not only saves certification time but also reduces associated costs. Different frequency versions of the RF4463PRO—such as RF4463PRO-433, RF4463PRO-868, and RF4463PRO-915—ensure compliance with various international standards.

RF4463PRO-433: Designed for the 433 MHz band, available in versions with and without CE and FCC certification.

RF4463PRO-868: Center frequency of 868 MHz, available in a CE-certified version.

RF4463PRO-915: Operates in the 915 MHz band, with both FCC and IC certifications.

Exemplary RF Performance: Balancing Stability and Low Power Consumption

This module is particularly well-suited for applications with stringent power requirements. The RF4463PRO boasts impressive ultra-low power consumption, drawing only 10mA in receive mode, and features an ultra-low power shutdown mode to significantly extend battery life. This design is crucial for IoT devices, remote metering, and industrial control scenarios, ensuring excellent communication quality while promoting energy efficiency.

Automatic antenna matching, bi-directional switch control, and frequency-hopping capabilities further enhance its interference resistance in complex RF environments, ensuring long-term reliable operation of the module.

Multi-Functional Configuration: Meeting Diverse Application Needs

The GPIO multi-functional configuration of the RF4463PRO module showcases exceptional flexibility across various application scenarios. Whether for home security alarms, industrial control, remote metering, or sensor networks, the RF4463PRO seamlessly integrates to enable stable wireless communication.

Other application areas include:

· Remote controls

· Home automation telemetry

· Health monitoring

· Wireless PC peripherals

· Tire pressure monitoring

· Toy control

The module's frequency hopping and timed wake-up functions ensure maximum link efficiency during data transmission while further enhancing its anti-interference capabilities.

Strict Production and Testing Standards

The RF4463PRO module is produced and tested using lead-free processes, ensuring compliance with RoHS and REACH environmental standards. Each module undergoes rigorous testing before leaving the factory to meet the highest industry standards. This strict quality control means customers can confidently deploy the RF4463PRO in critical communication areas.

Summary: A Future-Ready Wireless Communication Module

Whether you need stable data transmission in complex RF environments or wish to utilize wireless communication devices in remote monitoring and industrial control, the RF4463PRO module is your ideal choice. It boasts powerful performance and versatile configuration options, backed by multiple global certifications to ensure compliance worldwide.

If you'd like to learn more about the technical details or application solutions of the RF4463PRO wireless module, please feel free to contact our technical team. We are dedicated to providing you with professional support and guidance, helping you explore the limitless possibilities of wireless communication!

Key Points Summary:

International Certifications: Certified by FCC, CE, and IC, ensuring compliance in global markets.

High Performance: Utilizes (G)FSK narrowband transmission technology, with a sensitivity of -126dBm and output power of +20dBm.

Low Power Consumption: Only 10mA in receiving mode, with ultra-low power design suitable for long-term operation of wireless devices.

Wide Applications: Suitable for remote controls, remote metering, security alarms, industrial control, and more.

Flexible Configuration: GPIO multifunctional configuration, supporting custom frequency bands (142-1050MHz).
