STP201 : IIC Interface Wrist Applicaton 3D Pedometer Chip Set
- STP201 is a 3D pedometer module with functional IC chipset which include a G-sensor and MCU. It has adopted the standard IIC interface, with the 3D MEMS sensor (G sensor) and high precision of 3D pedometer algorithm, it can give a precisely pedometer in any direction. This chipset has the characteristics of small size, low power consumption and etc. The standard I2C digital interface ensures it can be easily embedded in various kinds of pedometer functional system.
- ★Note: The algorithm of our pedometer is adjustable according to customer’s requirement. We can provide the pedometer for shoes, table class pedometer and bracelet pedometer wearing on wrist, pedometer wearing on waist and pedometer putting inside the pocket. Pls indicate clearly when purchasing.
| Parameters | Condition | Performance | Unit | ||
| Min. | Typ. | Max. | |||
| Working voltage | 2.3 | 3 | 3.6 | V | |
| Working current | @3V | 80 | uA | ||
| Sleep current | < 5 | uA | |||
| Step resolution | 1 | Step | |||
| Pedometer wrror | Uniform Working | ± 3% | Step | ||
| Working temperature | -10 | 50 | ℃ | ||
| Storage temperature | -10 | 50 | ℃ |
| Special Function | Pedometer module |
Features
- IIC interface
- High precision 3D pedometer algorithm
- Wrist application
- Ultra-low power/Ultra-small size
Applications
- Wrist Pedometer
- Sports watch
- Outdoor handheld
- Healthcare products
