STP101 : Pulse Output For Wrist Application 3D Pedometer Chip Set
- STP101 is a 3D pedometer functional chipset which include a G-sensor and MCU for wirst application. It has adopted the pulse-type interface, with the 3D MEMS sensor (G sensor) and high precision of 3D pedometer algorithm, it can give a precisely pedometer in any direction. This module has the characteristics of small volume, low power consumption and high precision etc. The simple pulse ouput interface ensures it can be easily embedded in various kinds of pedometer functional system.
- Note:The algorithm of our pedometer is adjustable according to customer’s equirement. We can provide the pedometer for shoes, table class pedometer and bracelet pedometer wearing on wrist,pedometer wearing on waist and pedometer putting inside the pocket.
- Please indicate clearly when purchasing.
| Parameters | Condition | Performance | Unit | ||
| MIN | TYP | MAX | |||
| Working voltage | 2.3 | 3 | 3.6 | V | |
| Working current | @3V | 25 | uA | ||
| Sleep current | < 4 | uA | |||
| Step resolution | 1 | Step | |||
| Pedometer error | Uniform working | ±3% | Step | ||
| Working temperature | -10 | 50 | ℃ | ||
| Storage temperature | -10 | 50 | ℃ | ||
| Special Function | Pedometer module |
Features
- Pulse output interface
- Wrist application
- High precision 3D pedometer algorithm
- Low power consumption,Ultra-small size
Applications
- Bracelet pedometer
- Sport watch
- Outdoor handheld
- Healthcare products
