Difference between Uart LoRa module LoRa610II and LoRa610Pro
By sdga:NiceRF Wireless Technology Co., Ltd
LoRa610II and LoRa610Pro are both Uart LoRa modules launched by NiceRF. Here are the similarities and differences between the two LoRa modules.
Difference between Uart LoRa module LoRa610II and LoRa610Pro
1. Similarities between the two Uart LoRa modules:
- Built-in hardware reset protection circuit
- AES128 data encryption method
- LBT (Listen Before Talk) function optional
- Node/route/node+route optional in MESH mode
- Frequency band: 433/470/868/915 MHz for option
- LoRa modulation
- TTL interface
- No blind zone no distance limitation: Single module open transmission distance of 5Km @ low rate
- Up to 40 communication channels in the same frequency band
- Diversified serial port parameters
- Operating temperature range: -40 ~ +85 °C
- Application: wireless remote control, remote meter reading, industrial data acquisition, home automation telemetry, wireless data communication, access control system.
2. Differences between the two Uart LoRa modules:
| Product model | Uart LoRa module LoRa610II | Uart LoRa module LoRa610Pro |
| Chip | LLCC68 | SX127X |
| Maximum output power | 160mW | 100mW |
| Output power range | 1～22dBm | 4～20dBm |
| Built-in overcurrent and overvoltage reverse connection protection circuit | No | Yes |
| Receiving sensitivity | -129dBm | -139dBm |
| Working voltage | n1.8～3.7 V | 3.3～6.5 V |
| Receiving current | <8mA | <15mA |
| Transmitting current | <110mA | <130mA |
| Sleeping current | <5uA | <200uA |
| Modulation rate | 1312～17353bps | 91～17353bps |
| Size (length* width*height) | 29.85*16.1*3mm | 39.55*22.93*3.15mm |
That’s all about the differences between LoRa module LoRa610II and LoRa610Pro and hope it’s helpful.
