New Product Launch: Brand New 8-Channel Concurrent Full-Duplex Data Transmission Module with Ultra-Low Latency Wireless Communication

NiceRF has newly launched the SA618F30-FD, an 8-channel full-duplex wireless data communication module capable of handling up to 8 transmitters simultaneously without interference. It is designed for scenarios where multiple transmitters operate simultaneously in complex environments, minimizing the need for retransmissions and greatly reducing the chances of interference or being interfered with. The module combines LoRa modulation with 1W output power and features a low-power design for receiving and sleep modes, making it ideal for long-distance wireless IoT applications.

The SA618F30-FD full-duplex data transmission module integrates a high-speed microcontroller, high-performance RF transceiver chip, and power amplifier. It offers a standard serial port for easy communication with the module, allowing users to quickly set module parameters and control transmission and reception functions. Users simply need to connect the module to a serial port to achieve data transmission. Its ultra-compact size also allows for easy integration into various handheld devices.

Technical Specifications of SA618F30-FD

 Frequency Band 410~490MHz (Customizable 150-960 MHz)

 Up to 8 devices can transmit simultaneousl (no limit on reception)

 Echo cancellation function

8-way dynamic changes

Support OTA &Serial upgrade

3-4KM transmission distance in the open area

 High reception sensitivity: -117 dBm

Highly integrated and compact size

Core Advantages of the SA618F30-FD Full-Duplex Data Transmission Module:

The SA618F30-FD module introduces a new full-duplex feature, allowing simultaneous data transmission and reception, making the communication process more efficient. In traditional half-duplex communication, transmission and reception must alternate, but full-duplex eliminates this limitation, enabling continuous, real-time communication.

Full-Duplex Communication with 8-Channel Concurrent Operation (without Interference): Supports 8-channel concurrent communication where the receiving end is unrestricted, greatly reducing the likelihood of retransmission. Multiple transmitters can operate simultaneously without interference, ensuring seamless connection and smooth operation even when multiple sources are transmitting data at the same time.

Low Latency: The module is optimized for minimal transmission delay. Compared to other half-duplex data transmission modules, the full-duplex module achieves a latency rate of less than 50ms.

Long-Range, Low-Power Communication: The SA618F30-FD utilizes LoRa modulation technology, combined with 1W output power, enabling transmission distances of 3-4 kilometers in open environments. Its low-power design ensures efficient performance in both receiving and sleep modes.

ESD Protection: Built-in electrostatic discharge (ESD) protection prevents damage caused by static electricity, enhancing the durability and stability of the module.

Customizable AES Encryption: Users can customize AES encryption functionality based on their needs to enhance the security of data transmission.

Dynamic 8-Party Changes: The module allows up to 8 people to communicate simultaneously, with the added flexibility of allowing participants to join or leave the conversation at any time, providing users with great adaptability.

Other Features of the SA618F30-FD Full-Duplex Data Transmission Module:

Efficient Transmission Performance

The SA618F30-FD utilizes advanced LoRa modulation technology, combined with 1W output power, achieving a transmission distance of up to 3-4 kilometers in open environments. The module also boasts a high reception sensitivity of -117 dBm, ensuring stable data reception even under weak signal conditions.

High Integration and Low Power Consumption Design

The module integrates a high-speed microcontroller, high-performance RF transceiver chip, and RF power amplifier, creating a highly integrated design that significantly reduces system size and cost. Additionally, the SA618F30-FD's low power consumption design ensures energy efficiency during long-term operation, extending the device's lifespan.

Flexible Configuration and Upgrades

The SA618F30-FD module offers a standard serial port, allowing users to quickly configure module parameters and control its transmission and reception functions through a simple serial connection. Moreover, the module supports OTA (Over-the-Air) and serial upgrades, enabling users to easily expand functionality and optimize performance without hardware changes.

Multiple Protections, Robust and Durable

The module features built-in ESD electrostatic protection and both software and hardware crash protection mechanisms, enhancing its durability and stability to withstand various harsh environments.

Application Areas of the SA618F30-FD Module:

AGV (Automated Guided Vehicles): In AGV systems, the low-latency full-duplex data transmission capability ensures real-time communication between the AGV and the control center.

Tower Crane Systems: For tower crane operations, the high-power and long-distance communication capabilities ensure the real-time and reliable control of the crane. The full-duplex function allows operators to simultaneously send and receive commands, preventing safety hazards caused by communication delays or interruptions.

Multi-Channel Full-Duplex Data Transmission Applications: In complex scenarios where multiple devices need to communicate simultaneously, the 8-channel concurrent full-duplex functionality is critical, allowing devices to communicate at the same time without interference.

The new product is now available. We welcome users to visit NiceRF official website : www.nicerf.com to learn more about the advantages of the SA618F30-FD module and its innovative technology.
