125KHz wireless over air wake-up and data transceiver module RF125 distance test

125KHz module RF125 introduction

Our RF125 is a low-power, long-distance, wireless air wake-up and 125KHz module used in RKE keyless access control, campus access control, etc. How far is the communication distance of this product? Next, the editor of NiceRF will demonstrate the actual test process.

125KHz module RF125 test preparation tool

125KHz transmitter module RF125-TX and RF125-RA (integrated 125KHz receiver module RF125-RX, two 125K antennas, battery slices, buttons) and battery (voltage: 9~12V).

（125KHz transmitter module RF125-TX）

（RF125-RA）

（Battery）

125KHz module RF125 test process

Next, the test is performed. The test location is selected on the roof of an open place, the battery connector is inserted into the 125KHz transmitter module RF125-TX, and the power is turned on. Then the red light on the RF125-TX starts to flash, indicating that data is being transmitted.

①Ranging distance 6m: Put the RF125-RA 6m away from the RF125-TX module. The test position has a row of railings. The distance of each railing is measured to be 1m. The editor puts it at the position of the 6th railing and observes Does RF125-RA receive data? If the blue light of RF125-RA starts to flash, it means that the data has been successfully received.

（6m test environment: 125KHz module RF125 transmitting and receiving data status）

It can be seen from the figure above that after the RF125-TX module transmits data, the blue and red lights of the RF125-RA flash at the same time. The flashing blue light indicates that the data transmitted by the RF125-TX has been successfully received, and the flashing red light indicates that the RF125-RA wakes up. At the same time, it wakes up the connected device and the communication distance of 6m is tested successfully. (Note: Due to the small size of the RF125-RA, it is difficult to take pictures, so the editor put a battery next to it as a mark)

②Test distance 8m: Next, the editor moves the RF125-RA to the 8th section of the railing, which is 8m, and observes whether the RF125-RA receives data.

（8m test environment: 125KHz module RF125 transmitting and receiving data status）

It can be seen from the above figure that after the 125KHz transmitter module RF125-TX transmits data, the blue and red lights of the RF125-RA flash at the same time, indicating that the data has been successfully received and awakened, and the communication distance of 8m has been successfully tested.

The above is the sharing of the distance test of the 125KHz module RF125. It has a communication distance of 5-8m, far exceeding the same type of products. The 125KHz module of the same type currently on the market has a communication distance of only 4m. If you are interested in our low-power, long-distance, wireless air wake-up and data transceiver module RF125, welcome customers come to consult us @sales@nicerf.com.
