New: Low power, high accuracy multi-mode satellite GPS module GPS03 series

By sdga:NiceRF Wireless Technology Co., Ltd

In October 2022, NiceRF launched the GPS module GPS03 series. It is a application module that supports our company GPS01, GPS01-TD, GPS01-ZK, GPS02-UBX, GPS02-TD, with built-in self-charged spare battery, which can support heat start within 1 hour. It is extremely convenient for customers to apply.

Low power, high accuracy GPS module GPS03 series

GPS module GPS03 series introduction:

Product model	GPS03-01ZK	GPS03-01TD	GPS03-01	GPS03-02TD	GPS03-UBX
Support satellite navigation system	BDS/GPS/GLONASS	BDS/GPS/GLONASS/ Galileo	BDS/GPS/GLONASS	BDS/GPS/GLONASS/ Galileo	BDS/GPS/GLONASS/ Galileo(Choose three of four, BDS and GLONASS cannot be used at the same time.)
Auxiliary Satellite Navigation System	Support SBAS and QZSS	Support SBAS and QZSS	*	Support SBAS and QZSS	Support SBAS and QZSS
Position	Support A-GNSS assisted positioning	Support A-GNSS assisted positioning	Support A-GNSS assisted positioning	Support A-GNSS assisted positioning	Support A-GNSS assisted positioning
Operating mode	1. Support BDS, GPS, GLONASS, single system work; 2. Support dual system work; 3. Support BDS/GPS/GLNOASS three systems	1. Support BDS, GPS, GLONASS, Galileo single system work; 2. Support dual system work; 3. Support BDS/GPS/GLNOASS, BDS/GPS/Galileo three systems; 4. Support BDS/GPS/Galileo/GLNOASS four system work	1. Support BDS, GPS, GLONASS single system work; 2. Support BDS/GPS, BDS/GLNOASS, GPS/GLONASS dual system work	1. Support BDS, GPS, GLONASS, Galileo single system work; 2. Support dual system work; 3. Support BDS/GPS/GLNOASS, BDS/GPS/Galileo three systems; 4. Support BDS/GPS/Galileo/GLNOASS four system work	1. Support BDS, GPS, GLONASS, Galileo single system work; 2. Support dual system work; 3. Support GPS/Galileo/GLONASS BDS/GPS/Galileo three systems
Sensitivity	Capture: -148dBm Tracking: -162dBm	Capture: -147dBm Tracking: -163dBm	Capture: -147dBm Tracking: -163dBm	Capture: -147dBm Tracking: -163dBm	Capture: -148dBm Tracking: -166dBm
Time to first fix TTFF	Cold start ≤ 32s Hot start≤ 1s Recapture≤ 1s	Cold start <28s Hot start: 1s Recapture: 1s
Positioning accuracy @ open field	<2m	Level <3m Elevation <4.5m
Operating voltage range	VCC：3.3～5.5V
Receive current	<28mA	<35mA	<30mA	<35mA	<25mA
Sleep current	<10uA	<25uA	<20uA	<25uA	<35uA
Data update rate(Default 1Hz)	Single system: 1～5Hz Dual system: 1～5Hz Three systems: 1～5Hz	Single system: 1～20Hz Dual system: 1～10Hz Three systems: 1～10Hz Four systems: 1～10Hz	Single system: 1Hz Dual system: 1Hz	Single system: 1～20Hz Dual system: 1～10Hz Three systems: 1～10Hz Four systems: 1～10Hz	Single system: 1～18Hz Dual system: 1～10Hz Three systems: 1～10Hz
Serial port baud rate	9600～115200bps	4800～230400bps	4800～230400bps	4800～230400bps	4800～921600bps
Size (L*W)	27.99*28.80 mm

If you want to know more about the new GPS Module GPS03 series, please check our website: https://www.nicerf.com , and welcome to consult us @ sales@nicerf.com.
