STP100M : Pulse Output For Non-Wrist Application 3D Pedometer Module
- STP100M is a 3D pedometer module which include a G-sensor and MCU. It has adopted the pulse-type interface, with the 3D MEMS sensor (G sensor) and high precision of 3D pedometer algorithm, it can give a precisely pedometer in any direction. This module has the characteristics of small size, low power and etc. The simple digital interface ensures it can be easily embedded in various kinds of pedometer functional system.
- ★Note: The algorithm of our pedometer is adjustable according to customer’s requirement. We can provide the pedometer for shoes, table class pedometer and bracelet pedometer wearing on wrist, pedometer wearing on waist and pedometer putting inside the pocket.Pls indicate clearly when purchasing.
| Parameters | Condition | Performance | Unit | ||
| Min. | Typ. | Max. | |||
| Working voltage | 2.3 | 3 | 3.6 | v | |
| Working current | @3V | 80 | uA | ||
| Sleep current | < 4 | uA | |||
| Step resolution | 1 | Step | |||
| Pedometer wrror | Uniform Working | ±3% | Step | ||
| Working temperature | -10 | 50 | ℃ | ||
| Storage temperature | -10 | 50 | ℃ |
| Special Function | Pedometer module |
Features of 3D Pedometer Module STP100M
- High precision 3D pedometer algorithm
- Pulse output interface
- Low sleep current
- Ultra-small size
Applications of 3D Pedometer Module STP100M
- 3D pedometer
- MP3 pedometer
- Outdoor handheld
- Healthcare products
- Pedometer shoes
| Pin NO. | Pin name | Description |
| 1 | GND | Connect ground |
| 2 | GND | Connect ground |
| 3 | VCC | Connect positive power（2.3-3.6V） |
| 4 | GND | Connect ground |
| 5 | STEP | Pulse-output pin |
